Product Details:
|
| Protect Feature: | Drip-proof | Phase: | Three-phase |
|---|---|---|---|
| AC Voltage: | 380V | Frequency: | 60Hz |
| Usage: | Electric Tool | ||
| High Light: | 300rpm High Torque Asynchronous Motor,35kW High Torque Asynchronous Motor,380V low speed induction motor |
||
300rpm 35kW Low Speed High Torque Asynchronous Motor
This is a typical AC electrical motor that is capable of producing synchronous speeds. In these motors, both the stator and the rotor rotate at the same speed thus achieving synchronization. The basic working principle is, when the motor is connected to the mains, electricity flows into the stator windings, producing a rotating electromagnetic field. This is in turn induced on to the windings in the rotor which then starts rotating.
An external D.C source is required to lock the rotor’s rotating direction and position with that of the stator. As a result of this interlocking, the motor has either to run synchronously or not run at all.
|
Rated power (kW)
|
35kW
|
|
Rated speed (rpm)
|
300rpm
|
|
Rated torque (Nm):
|
1114Nm
|
|
Rated voltage (V):
|
380VAC
|
|
Rated current (A):
|
53A
|
|
Number of poles
|
4
|
|
Frequency (Hz)
|
60Hz
|
|
Phase
|
3-phase
|
|
Insulation Class:
|
H
|
|
Protection Class
|
IP54
|
|
Efficiency(﹥%)
|
94%
|
|
Power factor
|
0.97
|
|
Cooling
|
Air cooling
|
|
Mechanical specifications
|
|
|
Installation
|
Horizontal
|
|
Frame size
|
250
|
|
Weight (Kg)
|
420kg
|
|
Materials
|
|
|
Shaft material
|
Steel
|
|
Bearings
|
Steel
|
|
Housing material
|
Casting iron
|
|
Winding material
|
Copper
|
|
Winding temperature level
|
180℃
|
|
Magnet
|
NdFeB
|
|
Magnet temperature level
|
150℃
|
|
Core
|
High quality cold rolled silicon steel sheet
|
