Single Shaft Planetary Gear Motor Micro NEMA23 Worm Gear Motor 1.89N.M

Single Shaft Planetary Gear Motor Micro NEMA23 Worm Gear Motor 1.89N.M
Single Shaft Planetary Gear Motor Micro NEMA23 Worm Gear Motor 1.89N.M

Large Image :  Single Shaft Planetary Gear Motor Micro NEMA23 Worm Gear Motor 1.89N.M

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Payment Terms: T/T
Supply Ability: 10000 piece/pieces per month

Single Shaft Planetary Gear Motor Micro NEMA23 Worm Gear Motor 1.89N.M

Description
Name: Gear Reducer Stepper Motor Current: 2.8A - 4.2A
Step Angle:: 1.8 Degree Leads: 4 / 6 / 8
Holding Torque: 1.89N.m IP For Gearbox: Gear Motor
Protect Feature: Drip-proof Construction: Permanent Magnet
High Light:

2.8A Planetary Gear Motor

,

1.89N.m Planetary Gear Motor

,

NEMA23 micro worm gear motor

DC Small Geared Stepper Motor NEMA23 High Precision Gear Ratio 1/3 - 1/1000 0.55N.M - 3.1N.M



Stage one stage two stage three stage
Ratio 3 4 5 8 10 12 16 16 20 25 32 40 64 100 64 80 100 120 125 160 200 256 320 512 1000
Max.input rpm(rpm)6 6000 6000 6000
Max.radial load(N) 550 550 550
Max.shaft axial load(N) 500 500 500
efficiency(%) 96 94 90
Backlash arcmin(arcmin) ≤8 ≤10 ≤12
Noise(dB) ≤60 ≤60 ≤60
Weight(kg) 3.2 3.9 4.8
Average useful life(h) >10000 >10000 >10000
Lubricating system long-term long-term long-term
Rotation direct input/output syntropy input/output syntropy input/output syntropy
Protection level IP65 IP65 IP65



Motor Length

Current

/Phase

Resistance

/Phase

Inductance

/Phase

Holding Torque

# of Leads

Detent Torque

Rotor Inertia

Mass

(L1)mm A Ω mH N.m No. g.cm g.cm Kg
41 2.8 0.7 1.4 0.55 4 250 150 0.47
51 2.8 0.83 2.2 1.01 4 300 230 0.59
56 2.8 0.9 2.5 1.2 4 350 280 0.68
64 2.8 0.8 2.3 1 4 400 300 0.75
76 2.8 1.1 3.6 1.89 4 600 440 1.1
82 3 1.2 4 2.1 4 1000 600 1.2
100 4.2 0.75 3 3 4 1100 700 1.3
112 4.2 0.9 3.8 3.1 4 1200 800 1.4



1. Using Enameled Copper Wire, Not Enamelled Aluminium Wire, So the motor is more reliable and long lifetime.
2. Low noise, Long lifetime.
3. More stable and safer when driving.



Company Introduction
Changzhou paliwei Motor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.

Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.



Q: How to order?
A: send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit → mass production →cargo ready → balance/delivery → further cooperation



Q: How about Sample order?
A: Sample is available for you. please contact us for details. Once we charge you sample fee, please feel easy, it would be refund
when you place formal order.



Q: Which shipping way is available?
A: DHL, UPS, FedEx, TNT, EMS, China Post,Sea are available. The other shipping ways are also available, please contact us if you
need ship by the other shipping way.



Q: How long is the deliver[Producing] and shipping?
A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.



Q: My package has missing products. What can I do?
A: Please contact our support team and we will confirm your order with the package contents.We apologize for any inconveniences.



Q: How to confirm the payment?
A: We accept payment by T/T, PayPal, the other payment ways also could be accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.
