12 - 24v Permanent Magnet DC Motor 67mNm at 5100rpm 56-78mm Length 29W 2.92A

China 12 - 24v Permanent Magnet DC Motor 67mNm at 5100rpm 56-78mm Length 29W 2.92A supplier

Large Image :  12 - 24v Permanent Magnet DC Motor 67mNm at 5100rpm 56-78mm Length 29W 2.92A

Product Details:

Place of Origin: CHINA
Brand Name: 3X MOTION
Certification: ISO9000, ROHS, CE
Model Number: 40ZYT Series

Payment & Shipping Terms:

Minimum Order Quantity: 10
Price: negotiation
Packaging Details: carton, pallet
Delivery Time: within 4 weeks
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 25,000pc/month
Detailed Product Description
Voltage Range: 12 & 24v Dc (240v Also Available) Power Output Range: 15 To 40 Watts
Speed Range: Up To 10,000rpm Operational Temperature: -20°C To +40°C
Insulation Class: F(consult Us For Class B) Bear Type: High Quality Ball Bearings
Housing Type: Closed(ventilated Also Available)

Permanent magnet Brushed DC Motors 40ZYT, 67mNm at 5100rpm 56-78mm Length 29W 2.92A 12 - 24v dc





General specification

Voltage Range

12 & 24v dc (240v also available)

Power Output Range

15 to 40 watts

Speed Range

up to 10,000rpm

Operational Temperature

-20°C to +40°C

Insulation Class

F(consult us for class B)

Bear Type

High quality ball bearings

Housing Type

Closed(ventilated also available)





Performance Data

Part Number

Voltage

Rated Power

Rated Speed

Rated Torque

Rated Current

No load Speed

Length

Units

V

W

rpm

mNm

A

rpm

mm

40ZYT56-12V

12

17

4950

33

1.8

6000

56

40ZYT61-12V

12

23

5100

43

2.39

6100

61

40ZYT78-12V

12

29

5000

67

2.92

5000

78

40ZYT56-24V

24

17

4950

33

0.89

6100

56

40ZYT61-24V

24

23

5100

43

1.17

6100

61

40ZYT78-24V

24

29

4200

67

1.46

5000

78





Description



3X MOTION Hybrid permanent magnet brushed DC motor are widely used in rotary pumps, clay pigeon traps, electric vehicles, golf carts, hoists, winches and a multitude of other applications



Customization Options



Brake:

All permanent magnet brushed DC motors can be supplied with a choice of 12 or 24V parking brake. An optional manual brake release is also available.



Encode:

3X MOTION permanent magnet brushed motors can be supplied with a variety of encode types and resolutions.



Custom shaft:

All permanent magnet brushed DC motors are available to order with a wide selection of custom shaft configurations.



Applications:

  • solar
  • automobile
  • communication
  • inkjet printer
  • pump
  • medical
  • blower
  • security



12 - 24v Permanent Magnet DC Motor 67mNm at 5100rpm 56-78mm Length 29W 2.92A

Dimensions in mm
