0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque

I'm Online Chat Now

0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque

0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque
0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque

Large Image :  0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque

Product Details:
Place of Origin: China
Brand Name: PV
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: cartons
Delivery Time: 3-4weeks
Payment Terms: T/T
Supply Ability: 50000 Per Month

0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque

Description
Product Name: BLDC Motor Rated Voltage: 24VDC
Current / Phase: 6.3A Rated Torque: 0.25N.m
Rated Speed: 4000rpm Phase: 24VDC
Number Of Poles: 8 Commutation: Brushless
High Light:

4000RPM DC Motor

,

0.25N.m High Speed DC Motor

,

12 Volt DC Motor High Torque

4000RPM High Speed Brushless DC Motor , 12 Volt DC Motor High Torque



A motor converts supplied electrical energy into mechanical energy. Various types of motors are in common use. Among these, brushless DC motors (BLDC) feature high efficiency and excellent controllability, and are widely used in many applications. The BLDC motor has power-saving advantages relative to other motor types.



Brushed motor Brushless motor
Lifetime Short (brushes wear out) Long (no brushes to wear)
Speed and Acceleration Medium High
Efficiency Medium High
Electrical Noise Noisy (bush arcing) Quiet
Acoustic Noise & Torque Ripple Poor Medium (trapezoidal) or good (sine)
Cost Lowest Medium (added electronics)



Number Of Phase Phase 3
Number Of Poles Poles 8
Rated Voltage VDC 24
Rated Speed Rpm 4000
Rated Torque N.m 0.0625 0.125 0.185 0.25
Rated Current Amps 1.8 3.3 4.8 6.3
Rated Power W 26 52.5 77.5 105
Peak Torque N.m 0.19 0.38 0.56 0.75
Peak Current Amps 5.4 10.6 15.5 20
Back E.M.F V/Krpm 4.1 4.2 4.3 4.3
Torque Constant N.m/A 0.039 0.04 0.041 0.041
Rotor Inertia g.cm^2 24 48 72 96
Body Length mm 41 61 81 100
Weight Kg 0.3 0.45 0.65 0.8
Sensor Honeywell
Insulation Class B
Degree of Protection IP30
Storage Temperature -25~+70℃
Operating Temperature -15~+50℃
Working Humidity 85% or under 85% RH(non condensing)
Working Environment outdoor(no direct sunlight),Non-corrosive Gas,
Non-inflammable gas, No oil fog, No dust
Altitude 1000m or under 1000m



Product Description

1. Three phase BLDC motor;
2. Made of anti-high temperature permanent magnet and high quality cold-rolled steel sheet;
3. CNC machine engraved axle, high quality bearing;
4. Alluminium alloy cap, plastic insulation, copper wires auto-wired.
5. Featured by its low noise, low vibration, low heating, of stable performance;
6. Excellent internal damping, can be used by different industries and under any circumstances, long lifespan.



Ideal Applications for BLDC Motors



We can expect to see BLDC motors used in a wider range of applications in the future. For example, they will probably be widely used to drive service robots—small robots that deliver services in fields other than manufacturing. One might think that stepper motors would be more suitable in this type of application, where pulses could be used to precisely control positioning. But BLDC motors are better suited to controlling the force. And with a stepper motor, holding the position of a structure such as a robot arm would require a relatively large and continuous current. With a BLDC motor, all that would be required is a current proportionate to the external force—allowing for more power-efficient control. BLDC motors may also be replacing simple brushed dc motors in golf carts and mobility carts. In addition to their better efficiency, BLDC motors can also deliver more precise control—which in turn can further extend battery life.





0.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque 00.25N.m 12 Volt 4000RPM High Speed DC Motor High Torque 1
